Trinex Power VM IV-4000 TWIN Hybrid Solar Inverter
Charge Voltage: 27 VDC · communication interface: USB/RS232/RS485/WiFi/Dry-contact · Voltage range: 170-280 VAC (For Personal Computers) 90-280 VAC (For Home Appliances) · Operating Voltage: 60 ~ 450 VDC
Price checked 29 Sept 2026. Confirm current availability with our team.
Product specifications
Brand: Trinex Power Model: TRIX-02 Charge Voltage: 27 VDC communication interface: USB/RS232/RS485/WiFi/Dry-contact Voltage range: 170-280 VAC (For Personal Computers) 90-280 VAC (For Home Appliances) Operating Voltage: 60 ~ 450 VDC Battery Voltage: 24 VDC Efficiency: 90% ~ 93% Input Current: 27A Transfer Time: 10 ms (For Personal Computers) 20 ms (For Home Appliances) Array Power: 5000W Rated Power: 4000VA/4000W Surge Power: 8000VA AC Voltage: 230VAC ± 10% Charge Current: 120A Charger Type: MPPT Frequency Range: 50 Hz/60 Hz (Auto sensing) Overcharge Protection: 33 VDC Voltage: 230 VAC Waveform: Pure sine wave Weight: 10 kg Dimension: 119 x 313.6 x 457.5
