Trinex Power VM IV-6000 TWIN Hybrid Solar Inverter
Charge Voltage: 54 VDC · communication interface: USB/RS232/RS485/WiFi/Dry-contact · Voltage range: 170-280 VAC (For Personal Computers) 90-280 VAC (For Home Appliances) · Operating Voltage: 60 ~ 450 VDC
Price checked 29 Sept 2026. Confirm current availability with our team.
Product specifications
Brand: Trinex Power Model: TRIX-03 Charge Voltage: 54 VDC communication interface: USB/RS232/RS485/WiFi/Dry-contact Voltage range: 170-280 VAC (For Personal Computers) 90-280 VAC (For Home Appliances) Operating Voltage: 60 ~ 450 VDC Battery Voltage: 48 VDC Efficiency: 90% ~ 93% Input Current: 27A Transfer Time: 10 ms (For Personal Computers) 20 ms (For Home Appliances) Array Power: 6000W Rated Power: 6000VA/6000W Surge Power: 12000VA AC Voltage: 230VAC ± 10% Charger Type: MPPT Circuit voltage: 500 VDC Frequency Range: 50 Hz/60 Hz (Auto sensing) Humidity: 5% to 95% Relative Humidity (Non-condensing) Operating Temperature: -10°C to 50°C Overcharge Protection: 63 VDC Voltage: 230 VAC Waveform: Pure sine wave Weight: 12 kg Dimension: 119 x 313.6 x 457.5
